Vessel Name: Enhanced Hot Separator
Size: 5′-2″ID x 32′-11″ T/T
Thickness: 3″
Weight: 112,063
Material: SA387 Gr 11 Cl 2
Industry: Refining
Vessel Name: High Pressure Separator
Size: 5’ID x 24’
Thickness: 3-1/8”
Weight: 77,838
Material: SA516-70N/Incoloy 825 Clad
Industry: Refining
Fabricated using SAW (tandem arc), GTAW, and FCAW welding processes. We also used Semi-automated circle SAW machine on the larger nozzles. CRO (Corrosion Resistant Overlay) was performed on all nozzle bores and faces. 30mm strip electrode was used for all long seams and girth seam lane closures. We mechanically stripped back all edges of cladding prior to welding the backer material. Equipment included Q-Lip nozzles, shoepentoeter, insulation, demister and we followed API 934-C. Inspection included WFMT and PMI.
